Built-in Gas Hobs · BHA-HB-90S6BF
90 cm 4-Gas + 2-Electric Built-in Hob
Six-burner 90 cm hob on a 430 stainless panel with cast-iron supports and electronic pulse ignition.
- ✓4 gas + 2 electric burners
- ✓AISI 430 stainless panel
- ✓Cast-iron pan supports
- ✓3.4 kW triple-ring wok burner
- ✓1.5 V electronic pulse ignition
- ✓LPG / NG / TG compatible
Product description
A 90 cm built-in hob combining four gas burners with two electric zones, so wok cooking and precise low-heat work can happen side by side. The panel is AISI 430 stainless steel and the pan supports are cast iron, which hold heat and resist distortion far better than pressed steel.
Ignition is 1.5 V electronic pulse — no matches, no pilot. The unit is factory-set for LPG, NG or TG and the installer selects the injector set supplied in the box. Drop-in depth requirement is ≥65 mm.
Technical specification
| Panel material | AISI 430#S.S |
|---|---|
| Pan support | Cast iron |
| Configuration | 4 gas + 2 electric |
| Gas firepower | 3.4 + 1.1 + 1.5 + 1.5 kW |
| Electric power | 1.2 + 0.8 kW |
| Ignition | 1.5 V electronic pulse |
| Gas types | LPG / NG / TG |
| Cut-out depth | ≥ 65 mm |
| Gross / Net weight | 10.5 kg / 9.5 kg |
| Packing | 915 × 560 × 180 mm |
Specifications are those published by the production line for this model. Confirm the final sheet at order stage — small revisions are normal between production batches.
